Exclusive Manufacturer's Representative - Canada
Shrink Tubing & Identification
Industry leading aerospace and commercial heat shrink & non-shrink products.
Reliability & Compliance
Dunbar offers a comprehensive range of heat-shrinkable tubing products, developed to meet mission critical industry requirements including AS23053 Mil-Spec, UL, CSA, ISO 9001, ISO 14000, RoHS & REACH compliance. Dunbar's advanced cross-linking technology ensures consistent and reliable production output to maximize reliability.
High Reliability Designs
Single Wall Polyolefin
Temperature Range: -55°C to 135°C
Voltage Range: 300-600V
Shrink Ratio: 2:1, 3:1, 4:1
Flame Retardant
Dual Wall Polyolefin
Adhesive Lined
Temperature Range: -35°C to 150°C
Voltage: 600V
Shrink Ratio: 2:1, 3:2. 3:1, 4:1
Flame Retardant
Medium & Heavy Wall Tubing
Temperature Range: -55°C to 125°C
Voltage: 1000V
Shrink Ratio: 3:1
Flame Retardant
Specialty Tubing
Polyvinylidene Fluoride (PVDF) - High Abrasion & Cut-Resistance
Kynar (PVF2) - High Temperature & Chemical Resistance
Neoprene - Flexible & Flame Retardant Elastomeric Polyolefin - Diesel-resistant & Flexible
Viton® - Chemical & Abrasion Resistant
Teflon
Temperature Range: -75°C to 260°C
Voltage: 1400-2000V
Shrink Ratio: 1.3:1, 1.6:1, 2:1, 4:1, 1.5:1, 1.25:1
Flame Retardant
Non-Heat Shrinkable
PTFE Spiral Wrap
Convoluted PTFE
Convoluted ETFE
Flexible Polyolefin
Polytetrafluoroethylene Thin & Light Wall
Download Direct Wire Cable Line Card
